Hand series radiography
Study these flashcardsFree · spaced repetition · iPhone, Android, Mac & web
All cards
1
How many carpal bones are there
8
2
How many muscles types are in the hand and what are they?
2
Extrinsic and intrinsic
Extrinsic and intrinsic
3
What carpal bone forms first?
Capitate
4
What age does the capitate form at?
2 months
5
What carpal bone forms second?
Hamate
6
What age does the hamate form at?
4 months
7
What carpal bone forms third?
Triquetrum
8
What age does triquetrum form?
2 years
9
What carpal bone forms fourth?
Lunate
10
What age does the Lunate form?
4 years
11
What carpal bone form at similar times?
Scaphoid
Trapezium
Trapezoid
Trapezium
Trapezoid
12
What age does the pisiform develop
12 years
13
What are the two main indications for hand X-rays?
Acute trauma/ Arthritis
14
What is acute trauma
sudden high force event
15
what is stress injuries
injuries caused by repeated force over time
16
What is colles fracture
Distal radius fracture
17
What displacement occurs in colles
Dorsal
18
what type of fracture is colles
transverse
19
What is the most common method for a colles fracture to occur
FOOSH
20
What group of people does colles fracture occur in
High incidence in elderly people
21
what fracture is this
colles
22
what fracture is this
colles
23
Why are colles fractures more common in the elderly
osteoporosis
24
what is osteoporosis
low bone mineral density resulting in weaker bones
25
what fracture is this
colles
26
what fracture is this
smith's
27
How are colles fractures usually treated
cast immobilisation and closed reduction
28
what type of fracture is a smith's fracture
transverse fracture
29
what displacement occurs in simith's fracture
volar
30
what fracture is more common colle or smiths
colles
31
how do you treat a smith's fracture
closed reduction
32
what happens if a fracture is unstable
ORIF will be used
33
what fracture is this
smiths
34
what fracture is this
smiths
35
what fracture is this
smiths
36
what group of people may experience stress fractures
athletes
37
what fracture is this
bartons
38
what fracture is this
bartons
39
where does a barton fracture occur
Distal radius fracture
40
What type of fracture is bartons fracture
Intra-articular
41
group that mainly get bartons fracture
Males young
42
what fracture is this
bartons
43
what is a compilation of bartons fracture
high post traumatic arthritis
44
what is an intra-articular fracture
a fracture involving the joint of the bone
45
what does DRUJ stand for
distal radial ulnar joint
46
where does a galeazzi fracture occur
Distal middle radial shaft
47
what fracture is this
galeazzi fracture
48
who does a monteggia fracture mainly occur in
in children
49
what fracture is this
galeazzi fracture
50
what fracture is this
galeazzi fracture
51
what fracture is this
galeazzi
52
what fracture is this
boxer fracture
53
what fracture is this
boxer
54
what fracture is this
benett
55
what fracture is this
benett
56
what is the usual treatment fir a benett fracture
surgical fixation
57
why is surgical fixation needed for a benett fracture
instability
58
PA Hand: Patient Position?
Seated comfortably at the end of the X-ray table.
59
PA Hand: Hand Placement on IR?
Palm down (prone) directly onto the center of the Image Receptor.
60
PA Hand: Finger Position?
Fingers slightly abducted to avoid overlap.
61
PA Hand: Hand & Forearm Alignment?
Long axis of hand and forearm aligned with the long axis of the IR.
62
PA Hand: CR Angle?
Perpendicular to the IR.
63
PA Hand: CR Centering Point?
3rd Metacarpophalangeal (MCP) joint.
64
PA Hand: Collimation Borders?
Closely to the anatomy, including all hand bones (fingertips to carpals) and approximately 1 inch of the distal forearm.
65
PA Hand: How to check for hand/wrist rotation?
Equal concavity on both sides of the metacarpal shafts
Equal separation of the intermetacarpal spaces.
Equal separation of the intermetacarpal spaces.
66
PA Hand: What to check regarding finger separation?
Fingers well-separated with open interphalangeal (IP) joint spaces
